The USG FLEX H series provides an indispensable feature set to perfectly fit small business requirements as well as to gain essential security services needed to protect against cyberattacks. Nebula Control Center (NCC) offers multiple subscription options to meet customers’ needs. The Nebula Plus/Professional Pack give you peace of mind at more control over your network updates and visibility, or even the most advanced management of cloud networking.
Live demo: flex200h.zyxeldemo.com
Network interfaces
100M/1G Ethernet (RJ-45)
8
100M/1G/2.5G Ethernet (RJ-45)
-
1G/2.5G/5G/10G Ethernet (RJ-45)
-
1G SFP/10G SFP+
-
IEEE 802.3at (PoE+) Port
Port 8 (100HP only)
Total PoE budget (watts)
30
USB 3.0 Type-A
1
Console port
Yes (RJ-45)
Rack-mountable
-
Fanless
Yes
System Capacity & Performance *1
SPI firewall throughput (Mbps) *2
4,000
VPN throughput (Mbps) *3
900
IPS throughput (Mbps) *4
1,500
Anti-Malware throughput (Mbps) *4
1,000
UTM throughput (Anti-Malware and IPS) *4
1,000
Max. TCP concurrent sessions *5
300,000
Max. concurrent IPsec VPN tunnels *6
50
Recommended gateway-to-gateway IPsec VPN tunnels
20
Concurrent SSL VPN users
25
VLAN interface
16
Key Features
Security Service *7
Anti-Malware
Yes
IPS
Yes
Application Patrol
Yes
Web filtering
Yes
Reputation Filter
Yes
SecuReporter
Yes
Sandboxing
Yes
Security Profile Sync
Yes
Device Insight
Yes
SSL (HTTPS) inspection
Yes
Two-Factor Authentication
Yes
SD-WAN & VPN
WAN load balancing
Yes
Prioritize critical applications
Yes
VPN Protocol
IKEv2/IPSec, SSL, Tailscale *8
Nebula SD-VPN
Yes
Auto-link VPN
Yes
Manual-link VPN
Yes
VPN Topology
Yes
WLAN Management
Default Number of Managed AP
8
Secure WiFi *7
Yes
Maximum Number of Tunnel-Mode AP *9
6
24
Recommend max. AP in 1 AP Group
10
Management & Connectivity
Nebula Centralized Management
Yes
Device HA
-
Link Aggregation (LAG)
Yes
Concurrent devices logins (max.) *10
64
Burst login rate (users/30sec)
64
Power Requirements
Power input
100H: 12V DC, 2A
100HP: 19V DC,3.42A
Max. power consumption (Watt Max.)
100H: 17
100HP: 51.2
Heat dissipation (BTU/hr)
100H: 40.365
100HP: 194.5
Physical Specifications
Item
Dimensions (WxDxH)(mm/in.):
216 x 143 x 33/8.50 x 5.63 x 1.30
Weight (kg/lb.):
100H: 1.04/2.30
100HP: 1.05/2.31
Packing
Dimensions (WxDxH)(mm/in.):
278 x 189 x 99/10.94 x 7.44 x 3.89
Weight (kg/lb.):
100H: 1.62/3.57
100HP: 1.91/4.21
Included accessories
Power adapter
Power cord (100HP only)
RJ-45 to RS-232 cable for console connection
Environmental Specifications
Operating
Temperature: 0°C to 40°C / 32°F to 104°F
Humidity: 10% to 90% (non-condensing)
Storage
Temperature: -30°C to 70°C / -22°F to 158°F
Humidity: 10% to 90%(non-condensing)
MTBF (hr)
100H:
40°C/ 353878.1057 hr
25°C/ 602150.9604 hr
100HP:
40°C/ 289845.2327 hr
25°C/ 518347.4294 hr
Acoustic noise
-
Certifications
EMC
FCC Part 15 (Class B)
CE EMC (Class B)
RCM (Class B)
BSMI
Safety
LVD (EN62368-1)
BSMI
- Note:
- *: This matrix with firmware uOS1.35 or later.
- *1: Actual performance may vary depending on system configuration,network conditions, and activated applications.
- *2: Maximum throughput based on RFC 2544 (1,518-byte UDP packets).
- *3: VPN throughput measurement are based on RFC 2544 (1,424-byte UDP packets); IMIX: UDP throughput based on a combination of 64 byte, 512 byte, and 1424 byte packet sizes.
- *4: Anti-Malware (with Express Mode) and IPS throughput is measured using the industry standard HTTP performance test (1,460-byte HTTP packets). Testing done with multiple flows.
- *5: Maximum sessions are measured using the industry standard IXIA IxLoad testing tool.
- *6: Including Gateway-to-Gateway and Client-to-Gateway.
- *7: Requires a Zyxel service license to enable or extend feature capacity. SSL (HTTPS) inspection and Two-Factor Authentication are default supported features for any registered USG FLEX H device.
- *8: Local GUI only.
- *9: Available in Q3, 2026.
- *10: This is the recommend maximum number of concurrent logged-in devices.
